250kW Rubber Extruder Drive Control System

We delivered two 250kW extruder drive systems, featuring highly-specialised electrical control panel equipment within a Rittal VX bayed control panel with Rittal Blue-E cooling units, alongside;

  • a Control Techniques Unidrive M700 250kW variable speed drive,
  • a Woehner busbar system.

180kW Plastic Extruder Control System

Axis Controls have the expertise to design and build extruder control systems for applications of all shapes and sizes.  This panel consisted of;

  • a Rittal VX control enclosure,
  • a Woehner busbar system,
  • a range of Siemens control gear,
  • a 180kW Parker 690P variable speed drive.
  • 180kW Parker drives for extruder applications

    180kW Parker drives for extruder applications

  • Rittal VX bayed control panel for extrusion applications

    Rittal VX bayed control panel for extrusion applications

  • Woehner busbar systems for extrusion systems

    Woehner busbar systems for extrusion systems

  • Control panels for extrusion applications

    Control panels for extrusion applications

  • HIAB transport is available

    HIAB transport is available

  • Electrical control panels for extrusion applications

    Electrical control panels for extrusion applications


Control Techniques Unidrive M700 Closed-Loop Extruder System

Axis Controls have over 10 years of experience with the manufacture of electrical control panels for extruder applications; positioning ourselves as the go-to company for many plastics, rubber and polymer manufacturers and machine builders alike.

This system comprised of a;

  • 250kW Control Techniques variable speed drive, with encoder feedback,
  • Schneider control gear,
  • Rittal Blue e+ cooling unit,
  • A Wonher busbar system.
  • Extruder electrical control panel

    Extruder electrical control panel

  • Electrical control cabinet with Rittal e Blue+

    Electrical control cabinet with Rittal e Blue+

  • Control panels for rubber extrusion applications

    Control panels for rubber extrusion applications

  • Wohner busbar systems for electrical control units

    Wohner busbar systems for electrical control units


Control Techniques M700 VSD Extruder Application

Our most recent build was a multi-bay electrical extrusion control panel that consisted of a Siemens Simatic PLC (Programmable Logic Controller), alongside;

  • Wohner busbar system,
  • Siemens PROFIsafe,
  • ABB isolators,
  • A Schneider Eurotherm temperature controllers
  • Siemens Simatic PLC system.
  • Control Techniques extruder systems

    Control Techniques extruder systems

  • Multiple connectivity options with our extruder applications

    Multiple connectivity options with our extruder applications

  • Electrical control panel for an extruder application

    Electrical control panel for an extruder application


Sprint Electric DC Drive Extruder System

Axis Controls have recently been commissioned to manufacture an electrical control panel as a retrofit solution to an existing extrusion machine.  The operator control panel was designed to be mounted to the machine and features a digital display for both the extruder barrel speed and DC motor current.  This control panel comprises of;

  • Sprint Electric PLX40 DC Drive,
  • Wohner busbar system,
  • Pilz safety.





  • Sprint Electric DC drive control for an extrusion application

    Sprint Electric DC drive control for an extrusion application

  • Phoenix Contact PSU solutions for extruder applications

    Phoenix Contact PSU solutions for extruder applications

  • Axis Controls electrical control panels for extrusion solutions

    Axis Controls electrical control panels for extrusion solutions

  • Axis Controls manufacturers control panels for a range of applications

    Axis Controls manufacturers control panels for a range of applications

  • We manufacture control panels of all shapes and sizes

    We manufacture control panels of all shapes and sizes


Compact, and Powerful Electrical Control Panel

Axis Controls have the capabilities and expertise to manufacture control panels of all shapes, and sizes. This small, yet powerful panel packed an industry-leading Siemens SIMATIC S7 PLC, alongside;

  • An Omron Power Supply,
  • Inside a Schneider UL listed enclosure.
  • Schneider UL approved enclosures

    Schneider UL approved enclosures

  • Compact extrusion control solutions

    Compact extrusion control solutions

  • UL 508a approved extrustion control solutions

    UL 508a approved extrustion control solutions


ABB 2.2kW Extruder Control Panel

Axis Controls have the skills and capabilities to deliver fully-bespoke control solutions.  This solution for an OEM Machine Builder consisted of a wall-mounted alongside a machine-mounted control panel, comprising;

  • A Phoenix Contact Power Supply Unit (PSU),
  • ABB 2.2kW Variable Speed Drive (VSD),
  • Pilz Safety,
  • A Schneider UL approved enclosure.



  • Small, yet powerful machine-mounted control panels

    Small, yet powerful machine-mounted control panels

  • Wall mounted machines for extruder applications

    Wall mounted machines for extruder applications

  • ABB 2.2kW variable speed drive

    ABB 2.2kW variable speed drive


Parker 7.5kW Extruder Control Panel

In 2018, Axis Controls was commissioned by an OEM Machine Builder to manufacture an electrical control panel to be mounted to an extrusion machine.  This control panel comprised of;

  • A Parker 7.5kW AC690P Inverter,
  • Pilz Safety,
  • Phoenix Contact Relays,
  • Siemens Control-Gear and Circuit Breakers,
  • A Phoenix Contact Power Supply.
  • Rittal UL Approved Control Panel Enclosure

    Rittal UL Approved Control Panel Enclosure

  • Parker 7.5kW AC690P Inverter

    Parker 7.5kW AC690P Inverter

  • Parker variable speed drives for extruder applications

    Parker variable speed drives for extruder applications


Parker 15kW Machine-Mounted Control Panel

Axis Controls are often asked to design and manufacture control panels and automation solutions that are machine-mountable.  This electrical control panel was designed to be bolted onto an extrusion machine by our OEM Machine Builder customer.  This contains;

  • A Parker AC690P 15kW Variable Speed Drive,
  • A Rittal UL approved cabinet,
  • Pilz Safety,
  • Phoenix Contact Relays,
  • A Phoenix Contact PSU.
  • Machine-Mounted Extruder Control Panel

    Machine-Mounted Extruder Control Panel

  • Sick safety for extrusion applications

    Sick safety for extrusion applications

  • Parker AC690P 15kW Variable Speed Drive

    Parker AC690P 15kW Variable Speed Drive
