Axis Force Ventilation Fans for Brook Crompton WD Series Brake Motors

Axis Controls Economy Forced Ventilation Fans to fit Brook Crompton WD Series Brake electric motors are recommended for applications where the motor is used with a frequency inverter.

Consists of an extended fan cowl fitted with a motorised fan and a terminal box. The fan is designed to deliver the same (or more) cooling air that is normally delivered by the motors' own fan at the rated speed. Manufactured to provide IP66 protection.

CodeFrameVoltagePhasesRatingSize (mm)Price
FV INV 071 0K 133 284 071 230/400 V 1/3 Phases IP66 Ø: 133 L: 284 £195.75 Info/buy
FV INV 080 0K 154 275 080 230/400 V 1/3 Phases IP66 Ø: 154 L: 275 £195.75 Info/buy
FV INV 090 0K 174 294 090 230/400 V 1/3 Phases IP66 Ø: 174 L: 294 £199.50 Info/buy
FV INV 100 0K 195 317 100 230/400 V 1/3 Phases IP66 Ø: 195 L: 317 £204.00 Info/buy
FV INV 112 0K 211 325 112 230/400 V 1/3 Phases IP66 Ø: 211 L: 325 £212.50 Info/buy
FV INV 132 0K 253 355 132 230/400 V 1/3 Phases IP66 Ø: 253 L: 355 £236.25 Info/buy
FV INV 160 0K 309 410 160 230/400 V 1/3 Phases IP66 Ø: 309 L: 410 £309.00 Info/buy
FV INV 180 0K 352 445 180 230/400 V 1/3 Phases IP66 Ø: 352 L: 445 £359.25 Info/buy
FV INV 200 0K 409 457 200 230/400 V 1/3 Phases IP66 Ø: 409 L: 457 £447.00 Info/buy
FV INV 225 0K 448 461 225 230/400 V 1/3 Phases IP66 Ø: 448 L: 461 £442.50 Info/buy
